CCTV Security Surveillance Camera Network HD Lattice IR Camera JSA-8LAWPD75IP100/130/200 manufacturer from China Shenzhen JieShiAn Electronic Technology Co., Ltd

CCTV Security Surveillance Camera Network HD Lattice IR Camera

Price:	1.0 USD
Payment Terms:	T/T,L/C,D/A,D/P
Special Groups:	Civil Use (6) Professional Use (11)
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: JSA-8LAWPD75IP100/130/200

Production Capacity: 1000units/weeks

Delivery Date: 7-15days

CCTV security surveillance: security camera system

Means of Transport: Ocean,Land,Air

Packing: 1 units/box

CCTV Security System: CCTV Camera

Video bit-rate 1Mbps~8Mbps continuously adjustable;
Screen delay less than 200 ms( LAN );
Support DDNS, LAN, WAN access;

Company Name: Shenzhen JieShiAn Electronic Technology Co., Ltd
Website: jsa-cctv.com, jsashop.com
Contact Information:
Email:laixiaomei @jsa-cctv.com
MSN:shenzhenjsa @hotmail.com
Tel:0755-89968731-806
OICQ:2355298244
Skype:Emily_szjsa

Product Features:

Video bit-rate 1Mbps~8Mbps continuously adjustable;
Screen delay less than 200 ms( LAN );
Support DDNS, LAN, WAN access;
Voice intercom: two-way voice intercom, one-way voice broadcast;
Support dual-stream, network transmission and local storage are completely independent;
Support snapshot, video; optional 3G network linking;
Adopting H.264 video compression technology, high compression ratio, and work very flexibly;
Support video, alarm, voice data, built-in WEB Server, IE access;
Support for optional wireless WLAN(802.11g) , WEB search, WEP/WPA/WPA2 encryption;
Support SD card local storage, setting date and time;, optional support for cam monitor; support OSD;
Support HD resolution 1280*960, 1280*720, 1024*768, 800*600 resolution [720P];
LatticeIR laser device, strong brightness, irradiation distance, long servicelife; 10-20 meters infrared distance can be optional;
Support protocol PPPoE, DHCP, TCP/IP, HTTP, UDP, RTP/RTCP, RTSP, UPNP, SMTP, FTP, SIP, DDNS, DNS, ONVIF;
Support HD resolution 1920*1080, 1600*1200, 1280*960, 1280*720, 1024*768, 800*600 resolution [1080P];
Supportcompletely transparent RS485 interface, RS485 support one-way networktransparent channel connection, the client can control serial devicesthrough the network camera transparent channel;
Support 1channel video signal, real-time 25f/s independent compression, variablebit-rate and variable frame rate settings ,when set the video imagequality, can also limit compression stream of the video image at thesame time.

Technical Data Table

Order Series	JSA-8LAWPD75IP100	JSA-8LAWPD75IP130	JSA-8LAWPD75IP200
Camera Data
Sensor	1/3-type CMOS	1/2.5 inch CMOS
Effective Pixel	100 million pixel /720P	130 million pixel /720P	200 million pixel /1080P
Min-illumination	0.5 Lux[Color]] / 0.1 Lux[Black & White]	0.3 Lux[Color]] / 0.1 Lux[Black & White]
Standard	PAL/ NTSC
Lens	4MM,6MM Optional
S/N Ratio	50dB		55dB
Electronic Shutter	Auto exposure, 1/501/10K
Gamma Correction	0.45
White Balance	ATW/PUSH/USER1/USER2/ANTI CR/Manu/PUSH LOCK
BLC	Auto/ Manual
WDR	Unsupported	55dB	60dB
Day & Night	Black & White / Color or Auto color to black optional
IR Irradiation Distance	Lattice IR laser device,10-20meters optional
Compression Standard
Main Processor	TI368
Video Compression Standard	H.264/MJPEG
Compression Output Bit-Rate	32K4Mbps/1M20Mbps
Audio Compression Standard	G.711
Audio Output Bit Rate	64Kbps
Max-frame rate	PAL: 25 f/s, NTSC: 30 f/s
Functional Data
Cell phone Monitoring	Support Windows Mobile, Symbian, iPhone platform smart phone monitoring
Network Protocol	PPPoE, DHCP, TCP/IP, HTTP, UDP, RTP/RTCP, RTSP, UPNP, SMTP, FTP, SIP, DDNS, DNS, ONVIF
Motion Detection	Support
Region Shielding	Support
SD card local	Support
WIFI	Support optional 802.11b/g protocol,2.4GHz
3G Module	Optional built EVDO/WCDMA/TD-SCDMA
Series Interface	1RS-232 port( For data configuration, equipment maintenance, transparenttransmission)( Optional built-in, external interface without 232)
	1 RS-485 port(optional)
Alarm Interface	1 Input 1 Output (Optional)
Management Mode	IE/standalone management software/NVR/decoder/CMS platform server/third-party management platform
Others
Products Appearance	DC 12V;optional POE
Power supply	-10℃65℃
Working Temperature	85%RH Below
Working Humidity	IP 66
Dimension (mm)	200.2×89.1×80.4
Power Consumption	<8W
Optional Accessories	Rack:Wall-Mount or Lifting;Power Supply:DC 12V/2A
