Hot Selling 4-ch 960-DVR [KDA-DVR04H] Security DVR KDADVR04C manufacturer from China Shenzhen JieShiAn Electronic Technology Co., Ltd

Product Detail

Model No.: KDADVR04C

Production Capacity: 1000

Delivery Date: 7-15 working days

Means of Transport: Ocean,Land,Air

Packing: 1 unit/set

Hot Selling 4-ch 960-DVR [KDA-DVR04H] Security DVR

Product Features

1.Compression Technology: H.264 dual-stream compression technology, which can make the code stream lower more than 35%;

2.Display effect: HDMI(optional), VGA and BNC synchinput, It's better than the traditional monitoring display

3.Video recording Function: Video recording in full real-time (4-ch*960H, 8-ch*D1;16ch*D1),synchronously playback via all channels in full real-time;

4.Mobile Monitoring: iphone, Windows Mobile, BlackBerry, Symbian, Android;

5.HDD Interface: Support 2 SATA Interface;

6.Device Interface: Support 2 USB2.0 ports, USB Mouse, backup, record and upgrading etc;

7.Operating Interface: Like as WINDOWS operating style, the strong right mouse button which is very easy and comfortable to use;

8.Network Technology: The powerful Internet services (which support DHCP, PPPOE, DDNS and 3G), it is very easy to connect on devices;

9.DDNS System: All of our products are equipped with free domain name which can access to the Internet at any time to achieve the cloud monitoring;

10.Audio Processing: Access by audio monitor to achieve audio monitoring and data storage, as well as voice intercommunicating;

11.Others: Well-established protection circuit and unique triple watchdog function to make sure that the devices could operate consistently .

12.Black box' technology:With the unique 'black box' technology, it can monitor the operation of device to greatly reduce cost of maintenance;

13.Multiple Language:With 29 languages to option, it also can customize the language to realize OEM/ODM;

14.Packing Accessories: remote control, mouse, CD, Fast installation introduction, power supply, screw;

15.Customization: support to customize the start screens (with company's LOGO).

Technical Specifications

Model/Series	KDADVR04C/ KDADVR04D/ KDADVR04H /KDADVR0826 /KDADVR08D1
Main Processor	Industrial-grade embedded microprocessor
Operating System	Embedded LINUX OS
System Resources	Multi-channelvideo, video playback, network operations, USB backup
Display Split	1/4/8
Video Format	PAL: 625TVLines, 50 fps; NTSC: 525TVlines, 60fps
Monitoring Quality	PAL,D1(704×576); NTSC,D1(704×480)
PlaybackQuality	CIF,D1,960H
Code Capacity	CIF/D1/960H/2D1+6CIF/D1
Motion Detection	Zone: 396 ((22×18) Sensitivity: can be set multilevel sensitivity
Audio Compression	G711A
IntercomSystem	Support
Video Mode	Manual >Alarm >MD >Regular
Local Playback	Single Channel, multichannel
Video Query Method	Support time points, calendar, event and channel
HDD Space for each channel	Audio:28.8M byte/hour +video: 25450M byte/hour
Video Save	Local hard disk / Internet
Backup Mode	Internet/ USB/ USB Record
Video Input	4-ch BNC,1.0Vp-p, 75Ω 8-ch BNC,1.0Vp-p, 75Ω
Video Output	1-ch BNC,1.0Vp-p,75Ω,1-ch VGA output
Audio Input	4-ch RCA,200-3000mV,5KΩ
Audio Output	1-ch RCA,200-2800mV,30kΩ
Alarm Input	NA
Alarm Output	NA
Network Interface	RJ45 10M/100MAdaptable Ethernet interface
PTZ Interface	NA/Support( support all the PTZ control protocol)
USB Interface	2USB2.0
HDD Interface	1 SATA (Max: 3TB)
Power Supply	12V/3A
Power Consumption	<10W(Exclude HDD)
Working Temperature	0 ℃ +55 ℃
Working Humidity	10%90%
Atmosphere	86kpa 106kpa
Dimension	26023043mm
Weight	2kg
Packaging	10 unit/set, dimension of one packaging :495360555mm, weight of one set:23kg
